Ekonol aromatic polyester fillers are a key component in extending the life of parts & components made from PTFE compounds. The exceptional properties of Ekonol PTFE fillers provide maximum wear resistance, dimensional stability & corrosion resistance for molded or extruded parts in demanding services.
The highly crystalline Ekonol polymer yields unparalleled thermal stability along with good creep resistance & excellent load-bearing capacity. These features make Ekonol polyester PTFE fillers the ideal filler for PTFE compounds to increase service life of bearings, seals, rotors & related parts.
Whereas glass fillers can be abrasive, Ekonol fillers’ round particle shape will not wear soft metal surfaces. Additionally, Ekonol/PTFE blends resist self-wear better than other PTFE compositions, with good lubricity on molded parts
Data sheet
|
Property |
Test Method |
Values |
|
Specific Gravity |
ASTM D 4894 |
2.2g/cm3 |
|
Tensile Strength |
ASTM D 4894 |
10-15 mpa |
|
Elongation |
ASTM D 4894 |
180-250% |
|
Shore D Hardness |
ISO 868 |
56 |
|
Temperature Range |
- |
-200 oC - 260 oC |
|
Material |
- |
10% ekonol +PTFE |
